Brand | Samsung |
Model P/N | LTM170E6-L03 |
Diagonal Size | 17.0" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1280(RGB)×1024, SXGA 96PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 337.92(W)×270.336(H) mm |
Bezel Opening | - |
Outline Size | 358.5(W)×296.5(H)×17.5(D) mm |
Surface | Antiglare (Haze 44%), Hard coating (3H) |
Brightness | 250 cd/m² (Typ.) |
Contrast Ratio | 600:1 (Typ.) (TM) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
Display Mode | PVA, Normally Black, Transmissive |
Best View on | Symmetry |
Response Time | 15/10 (Typ.)(Tr/Td) |
Display Colors | 16.7M 100%sRGB |
Lamp Type | 4 pcsCCFL, Without Driver |
Frequency | 60Hz |
Touch Screen | Without |
Panel Weight | 2.10Kgs (Max.) |
Application | Desktop Monitor |
Signal Interface | LVDS (2 ch, 8-bit), 30 pinsConnector |
Input Voltage | 5.0V (Typ.) |
Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
